Equipment List

EQUIPMENT and CAPABILITIES

Xerox IGEN 5 150 – 1 Machine – 4 Color Variable Printer



  • PRINTING SPEED (150 8.5″ x 11″/A4 equivalent per minute)

    • 2,250 14.33″ x 35″ 4/0 sheets per hour

    • 3,000 14.33″ x 26″ 4/0 sheets per hour

    • 3,750 12″ x 18″/SRA3 4/0 sheets per hour

    • 4,500 11″ x 17″/A3 4/0 sheets per hour

    • 8,250 8.5″ x 11″/A4 4/0 sheets per hour

  • IMAGE QUALITY

    Resolution

    2400 x 2400 dpi Line Screens

    160 lpi, 180 lpi, 210 lpi, 250 lpi, Stochastic screening (white only)

    Object-Oriented Halftoning Process Colors

    Cyan, Magenta, Yellow, Black Xerox® Print Inspect Solution

    Electronic image quality assurance – 100% inspection of every page

  • PAPER FORMAT

    Standard Sheet Size

    14.33″ x 26″/364 mm x 660 mm Minimum 7″ x 7″/178 mm x 178 mm

  • IMAGE FORMAT

    Default image area is 3 mm less than sheet size

    Operator-adjustable to 1 mm to 6 mm per edge

  • PAPER WEIGHT (ALL TRAYS)

    Uncoated: 16 lb Bond to 130 lb Cover (60 gsm to 350 gsm)

    Coated: 60 lb Text to 130 lb Cover (90 gsm to 350 gsm)

  • PAPER FLEXIBILITY

    Coated, uncoated, text, cover, recycled, perforated, tabs, labels, synthetics, magnets, and a wide variety of specialty media

    Optional XLS capability for longer media up to 35″/889 mm

    Optional Thick Stock Capability for high caliper media up to 24 pt (610 microns)

    Mixed-stock jobs supported at rated speed

    No drying time

    Optional Acoustic Transfer Assist

  • TECHNOLOGY FEATURES

    Imaging

    ICC Source and Destination and Fast Path Profiling

    Color check for color monitoring

    Single-point transfer printing

    Color Maintenance Tool

    Closed-loop process controls with Inline Spectrophotometer

    CMYK or CMYK + optional 5th print station for White Ink

    Load dry inks while running

    Automated Image-on-Paper Setup





Xerox IGEN 4 – 2 Machines – 4 Color Variable Printers


  • Printing Speed

    Up to 6,600 full process color A4 (letter) 4/0 impressions per hour (110 impressions per minute)

    1,500 A3 (tabloid) 4/4 sheets per hour



    Image Quality

    Resolution

    600 x 4800 dpi
    Line screens – 150 lpi, 175 lpi, 200 lpi, 300 lpi,

    Process colors – Magenta, Yellow, Cyan, Black

  • Paper Format

    Maximum sheet size: 14.33″ x 20.5″ (364 x 521 mm); optional 14.33″ x 22.5″ (364 x 571 mm)

    Minimum sheet size: 7″ x 7″ (178 x 178 mm)

  • Image Format

    Maximum image area is 2 mm less than sheet size (1 mm border on all sides)

  • Paper Weight (all trays)

    Uncoated: 16 lb bond to 130 lb cover, 60 g/m2 to 350 g/m2

    Coated: 60 lb text to 130 lb cover, 90 g/m2 to 350 g/m2

  • Paper Flexibility

    Coated, uncoated, textured, specialty stocks

    Recycled, perforated, tabs, transparencies, a wide variety of labels, synthetics, DocuCard®, Never Tear, DuraPaper®, UltraMagnet, DocuMagnet

    Mixed-stock jobs supported at rated speed

    No drying time

    Transfer overdrive (optional)

    Technology Features

    SmartPressTM Imaging

    ICC Source and Destination and Fast Path Profiling

    Color check for color monitoring

    Single-point transfer printing

    Closed-loop controls with Inline Spectrophotometer

    Benchmark gamut of CMYK dry inks

    Load dry inks while running







Xerox Rialto Inkjet Press – 1 Machine 4 Color Variable Inkjet

  • Performance

    Rated speed

    • Up to 157 ft/min (48 m/min), 342 letter ipm / 322 A4 ipm, single pass duplex

  • Capabilities

    • Color continuous feed printing

    • Printed Sides

    • Duplex

    • MICR

  • Technology

    • PDLs

    • Xerox® Impika® PDF Controller: Adobe Acrobat® 9.0, PDF 1.7, PDF/X 1a, 3, 4, PDF V/T

    • Impika IPDS Controller: IPDS compliant to the AFP Consortium (IS/3) and encapsulated PDF

  • Imaging process

    • Drop-On-Demand (DOD) piezoelectric inkjet technology

  • Ink

    • Water-based pigment HD (high density)

  • Standard paper capacity

    • 31,000 ft.

    • Media Dimensions – Minimum 8.26″ (210 mm) wide

    • Media Dimensions – Maximum Up to 9.84″ (250 mm) wide

    • Media Weight – Minimum 60 g/m²

    • Media Weight – Maximum 160 g/m²

  • Media Types

    • Uncoated untreated, inkjet treated, inkjet matte coated





Finishing Equipment:

TEC Lighting – UV Coating Machine

PRODUCT INFORMATION

Want the best of both worlds? The Inline UV Coater offers all of the same features of the sophisticated TruCoat UV Coater, with added capabilities. This innovative design was created to accommodate and adapt to your existing printing equipment flawlessly. With its easy transfer inline conveyor table, professional UV coating becomes an accessible reality for your finishing needs. This technology offers high performance coating, and a quick and easy transport system to keep up with your fast-pace business.

• Works with all DIGITAL outputs

• Easy inline integration with most digital presses

• Graded transport conveyor for seamless transfer

• Adjustable height transfer table

• Modular design for easy mobility

• Offset and digital

• Xerox

• Ricoh

• Konica Minolta

• Canon

• HP

• OCE

• Screen digital

• Xante

• Up to 3,600 SPH

• Min 100lb Text

• 120 FPM

Double Kote High Speed Lamination System

Specifications

• Laminator Dimensions: 5′ W x 24′ 5″ L x 5’2″ H.

• Clearance: 5′ all sides.

• Warmup Time: 15 minutes.

• Max Laminating Film Roll Diameter: 18″.

• Laminating Film Thickness: 1.3mil – 15mil.

• Max Laminating Film Roll Weight: 150 lbs.

• Max Laminating Film Roll Width: 31″.

• Min Cut Sheet Size: 8.5″ x 11″.

• Max Cut Sheet Size: 31″ x 40″.

• Min Substrate Weight: 80 lbs text.

• Max Substrate Weight: 20 pt board.

• Sheet Feeder Pile Height: 29″.

• Lamination Speed: up to 125 fpm (feet per minute).

Cutters

Specifications

2 – Challenge 305 TC

Touch Controls

Fully Programmable

• Max. 30.75″ x 30.5″

• Min. 30.75″ x 2″

Folders

Specifications

MBO-B-30 w/right angle up to 16 page capability

MBO-B23C w/right angle

MBO-B26 w/right angle

• Folding speed of up to 25,000 pieces per hour. (Product Dependent)

• Sheet sizes: 14″ W x 26″L Maximum • 6″ W x 4″ L Minimum

Plow Folder

Nordson Multiple Head Glue Machines

• Equipped with glue, perforation & cut wheel attachments

Inserters

Specifications

3 – Flow Master

• Up to 6 Inserts

• Speed 10000-15000/hour (1 insert)
• 6 x 9 Largest Size Envelope

• 4 x 6.75 Smallest Size Envelope

Match Mail Systems

Specifications

Perfect Match
Barcode compatibility:

• Data matrix preferred barcode • Interleaved 2-of-5

• USS-128 (Code 128) • USS-39 (Code 3-of-9) • PDF417 • Invisible

• Read and print systems with speeds of up to 14,000 per hour

Inkjetting Speeds:

• 500ft per minute at 600x150dpi

• 250ft per minute at 600x300dpi

Inkjet print area: Scalable from 2”-16” of print

Product Attacher

Specifications

AT3 Product Attaching System

• Max. speed ‘20,000 pieces per hour (Product Dependent)

• Synchronized Servo Driven Card Feeder w/ Integrated Hot Melt Glue System

• Carrier Sizes: 12″ W x 14″ L Maximum • 3.5″ W x 4″ L Minimum

• Card Sizes: 3.3″ W x 6″L Maximum • 2.125″ W x 2.125″ L Minimum

Samples of items we can attach:
(Business Cards, Magnets, Credit Cards, Gift Cards, Insurance Cards, Post-it Note)

Tabber

Specifications

• Product Handling: Min. 3″ x 5″ – Max. 16″ x 17″
• Tab Specifications: Length 3/4″ to 2″ – Width Up to 2″

Other Finishing Capabilities

Hand Apply Fullfillment

• Small Run Shrink Wrapping

• Small Run Stitching

Technology Equipment and Software:

COMPUTER HARDWARE
Mac SSD Computer Stations
IBM Platform Computer Stations (Intel Dual Core)
State-of-the-Art Dell servers

COMPUTER SOFTWARE

• Adobe Creative Suite CC2020:

    • Photoshop

    • inDesign

    • Illustrator

    • Premiere

    • After Affects

    • Acrobat

• XMpie

IT DEVELOPMENT PROGRAM LANGUGES, FRAMEWORK & SCRIPT
PHP • .Net • XHTML • XML • HTML5 •YML • Javascript • Symphony • Ajax • MYSQL • Actionscript
